Honeywell M7284C1000-REB
Details
NOTE: PURCHASE OF THIS PRODUCT REQUIRES RETURN OF A REPAIRABLE CORE CONTROL. CLICK HERE FOR DETAILS.
Honeywell M7284C1000 Series 72 Modutrol IV™ Motor - Repaired by Acme Controls
Honeywell non-spring return motor used to control dampers and valves.
Features
| * | Integral junction box provides NEMA 3 weather protection. | |
| * | Field adjustable stroke. | |
| * | Nominal timing standard of 30 seconds (90° stroke), and 60 seconds (160° stroke). | |
| * | Dual shaft (slotted and tapped at both ends). | |
| * | Fixed torque throughout the entire voltage range. | |
| * | 4-20 mA drive signal. | |
| * | Two auxiliary switches. |
| Specifications | |
| Weight (lbs) | 10 |
| Voltage | 120 |
| Fail Safe | Non-Spring Return |
| Control Signal | 4 to 20 mA |
| Stroke | 90°-160° |
| Timing | 30s-60s |
| Torque | 150 lb-in |
