Honeywell V9055A1055-REB
Details
Honeywell V9055A1055 Modulating Fluid Power Gas Valve Actuator - Repaired by Acme Controls
Provides modulating control of the gas supply to commercial and industrial burners, when used in combination with a V5055, V5097, or VE5000 Gas Valve.
Features:
- Actuator opens to low-fire position when energized, then modulates to meet firing rate controller demand.
- Equipped with an integral damper shaft (20 lb. maximum @2-11/16 in. radius).
- Valve and actuator can be mounted in any position.
- All V5055, V5097, or VE5000 valves supported.
Switches and Safety Features
Switches on the V9055A1055 actuator are optional, including a a proof of closure switch or an internal auxiliary switch. If your actuator has these switches, do not remove them before shipment to us. It is also very important that your unit shipped for repair has all of the covers attached. Missing parts result in additional charges.
Specifications:
| Voltage: | 120 VAC | |
| Frequency: | 60 Hz | |
| Ambient Temp: | -40 to +125 F|-40 to +52 C | |
| Application: | Gas | |
| Shipping Weight: | 18 lbs | |
| Mounting: | Mount directly to valve bonnet with three setscrews |
Maximum Pressure: Rated up to 5 PSI for safe and reliable operation.
Maximum Closing Time: The actuator is engineered for safety, with a rapid shutoff feature that ensures it closes within one second when de-energized. This fast response helps protect both equipment and personnel by minimizing gas flow in emergency situations.
Visual Position Indicators: Easily monitor valve status at a glance—each unit features a clear visual indicator that signals the current position. A red marker appears when the valve is fully open, while a yellow marker denotes when the valve is securely closed. This helps you quickly confirm system status without additional tools or guesswork.
Gas Valves (sold separately):
| V5055A |
| V5055B (recommended) |
| V5055C |
| V5055D |
| V5055E |
| V5097A |
| V5097B (recommended) |
| V5097C |
| V5097D |
| V5097E |
Acme Control Service provides the best quality repairs on V9055A1055 and many other Honeywell products. You can recognize our work by its distinctive look. For over 80 years, we have been your favorite repair house's favorite repair house!
We have all UPS shipping services available and can ship your repaired V9055A1055 with your choice of expedited service.
Need more information or ready to take the next step? Request a quote now, or reach out to us at 1-800-621-6427 for expert assistance.
