R7795B1009-REB
Honeywell R7795A1001 Flame Safeguard Primary Control - Repaired by Acme Controls
Primary control provides flameout protection plus automatic control for commercial and industrial gas and oil burners.
Features* | Integral solid state rectification flame amplifier. | |
* | Solid state plug-in prepurge timers available. | |
* | Recycles through prepurge if flame signal is lost while in run. Failure to establish pilot results in a lockout. | |
* | Safe-start check prevents start-up if flame failure occurs. | |
* | Field selectable 10 or 4 second TPFI. | |
* | Mounts and removes easily through use of captive mounting screws. |
Specifications | |
Weight (lbs) | 3 |
Voltage | 120 |
Frequency | 50/60 Hz |
Ambient Temperature | -40 to +135°F | -40 to +57°C |
Electrical Connections | Q795 Subbase |
Shipping Weight | 4 |
Mounting | Q795A1004 Subbase |
Q795A1012 Subbase |
Acme recommends purchasing the entire package, including a timer. It will save you time and aggravation in the long run!
Don't forget your Prepurge Timer!!
|
Advance Replacement Services
This item, ending with -REB, is a repair service. In purchasing this service, you are agreeing to send us your non-functional, but repairable, control. It must not be burned, cannot have any water damage, and cannot be physically broken.
To simplify the return shipping process, a UPS Return Service (RS) Label will be added to your order and the cost of that return service will be included as a separate line item. You will receive a Return Merchandise Authorization (RMA) form and this UPS label in the carton along with the item(s) you have purchased.
Within 10 days of receiving your Rebuilt/Repair part, you must send your repairable control and RMA form back to Acme using the included UPS label. Failure to return a repairable core could result in additional charges of $200-$5000.
Cores returned after more than 10 days could result in late return fees of 10-100% of core charges.
This item, ending with -REB, is a repair service. In purchasing this service, you are agreeing to send us your non-functional, but repairable, control. It must not be burned, cannot have any water damage, and cannot be physically broken.
To simplify the return shipping process, a UPS Return Service (RS) Label will be added to your order and the cost of that return service will be included as a separate line item. You will receive a Return Merchandise Authorization (RMA) form and this UPS label in the carton along with the item(s) you have purchased.
Within 10 days of receiving your Rebuilt/Repair part, you must send your repairable control and RMA form back to Acme using the included UPS label. Failure to return a repairable core could result in additional charges of $200-$5000.
Cores returned after more than 10 days could result in late return fees of 10-100% of core charges.
