Honeywell M7284C1059-REB
Details
Modutrol IV Motor
| Specifications | |
| Weight (lbs) | 9 |
| Voltage | 120 |
| Frequency | 50/60 Hz |
| Ambient Temperature | -40 to +150 F|-40 to +60 C |
| Application | Electric |
| Fail Safe Mode | Non-Spring Return |
| Heading Control Signal | 4 to 20 mA |
| Internal Aux Switch | 2 |
| Shipping Weight | 9 |
| Mounting | Foot Mounted |
| Shaft Rotation | Clockwise |
| Stroke | 90 to 160 in. |
| Timing | 30 to 60 sec |
| Torque | 150 lb-in, 17 N-m |
