Honeywell M6284A1071-REB
Details
Modutrol IV Motor
| Specifications | |
| Weight (lbs) | 10 |
| Voltage | 120 |
| Frequency | 50/60 Hz |
| Ambient Temperature | -40 to +150 F|-40 to +66 C |
| Application | Electric |
| Fail Safe Mode | Non-Spring Return |
| Heading Control Signal | Floating, SPDT |
| Shipping Weight | 10 |
| Mounting | Foot Mounted |
| Shaft Rotation | Dependent on Wiring |
| Stroke | 90 to 160 Adjustable in. |
| Timing | 30 to 60 sec |
| Torque | 150 lb-in, 17 N-m |
